Product Description
Concord American VTR-3 30 ft Vertical Wall Mount Flagpole – VTR3-30C61
Pole price only. Truck freight is added at checkout. Enter your delivery ZIP code in the Get a freight quote box above to see your freight cost, then click Add to Cart with Freight. Freight is calculated from our Texas warehouse to your ZIP code. Residential delivery, liftgate service and call-ahead or appointment delivery may add charges; if your delivery needs any of these, we will call you to confirm the final freight cost before your order ships.
Vertical Wall Mount Series – External Single Revolving – Rope Halyard – Made to Order
The Vertical Wall Mount Series from Concord American Flagpole is a commercial-grade aluminum flagpole that mounts upright against the face of a building, so it can fly a full-size flag where there is no room for a ground-set pole. The VTR-3 uses two 4-bolt wall brackets with clamp collars (VW-3 4-bolt design) to hold the shaft to the wall. It comes with a gold anodized aluminum ball, a cast aluminum single revolving truck with aluminum pulley, a 5/16" polyester rope halyard with two solid brass swivel snap hooks and a 9" cast aluminum cleat. The revolving truck lets the flag turn freely with the wind. This 30 ft model has a 6" butt diameter and .156" wall. Vertical wall mount poles are popular on parking garages, office buildings, schools, hotels and storefronts. Each pole is made to order.
Specifications
| Model | VTR-3 (VW-3 4-bolt wall brackets) |
| Maximum mounting height | 30 ft (the shaft can be made shorter on request) |
| Butt (base) diameter | 6 in |
| Top diameter | 3.5 in |
| Wall thickness | .156 in |
| Shaft | Tapered aluminum, 1 piece |
| Recommended flag size | 6' x 10' |
| Approximate shipping weight | 161 lb (shaft 128 lb, hardware 33 lb) |
| Halyard system | External 5/16" #10 polyester rope halyard on a single revolving truck, tied off on a 9" cast aluminum cleat |
| Mounting | Vertical wall mount, VW-3 4-bolt brackets. Anchorage by others (see Wall Anchorage Kit option) |
| Catalog number | VTR3-30C61-*** (*** = finish code) |
Choosing the Right Height
The VTR-3 comes in 6 sizes:
- VTR3-15B41: 15 ft: 4" butt, .125" wall
- VTR3-20B41: 20 ft: 4" butt, .125" wall
- VTR3-25C51: 25 ft: 5" butt, .156" wall
- VTR3-30C61 (this model): 30 ft: 6" butt, .156" wall
- VTR3-30D61: 30 ft: 6" butt, .188" wall
- VTR3-35D61: 35 ft: 6" butt, .188" wall
The same sizes are available with other bracket styles: VTR-8, VTR-9. The VTR-3 uses 4-bolt brackets, the VTR-8 heavier 3-bolt brackets and the VTR-9 heavy-duty 8-bolt brackets.
Compare all Vertical Wall Mount flagpoles »
Standard Components
- Patented heavy-duty gold anodized aluminum ball
- Cast aluminum single revolving truck assembly with aluminum pulley
- Complete external halyard assembly: 5/16" #10 polyester rope halyard, two solid brass swivel snap hooks and two neoprene snap hook covers
- 9" cast aluminum cleat
- VW-3 4-bolt wall brackets
Wall anchorage (bolts and sleeves for your wall) is by others. See the Wall Anchorage Kit option below.
Finish Options
- Satin (SAT): brushed natural aluminum
- Bronze Tone Powder Coat (BZT)
- Black Powder Coat (BLK)
- White Powder Coat (WHT)
- Clear Powder Coat (CLR)
Available Options
- Cast aluminum sealed-bearing gold powder-coated ball and truck (8" or 10" ball) in place of the standard truck and ball
- Double revolving system (EDR): double truck, extra cleat and complete double halyard assembly, to fly two flags
- Locking cleat cover (cylinder lock or padlock)
- Wall Anchorage Kit WAK-9421 (one sleeve, one bolt, washers and nuts per kit; component pieces only)
- Flagpole lighting
Ask us about any of these options when you request your quote.
Frequently Asked Questions
How is it mounted?
The VTR3-30C61 attaches to the building with VW-3 4-bolt wall brackets. Anchorage to your wall is by others, so have your contractor or engineer choose the anchors for your wall type (brick, block, concrete or steel framing). Concord's WAK-9421 Wall Anchorage Kit is available as an option.
Can it be made shorter?
Yes. 30 ft is the maximum height for this shaft, and it can be cut to a shorter height on request. Let us know the height you need.
How is the flag raised and lowered?
The rope halyard runs from the revolving truck at the top and ties off on the 9" cast aluminum cleat. A locking cleat cover is available for added security.
How long does it take?
Vertical wall mount flagpoles are made to order, and lead times vary. Call us for a current lead time.
How does it ship?
The VTR3-30C61 ships by truck freight in one piece, with an approximate shipping weight of 161 lb. Freight is quoted to your ZIP code on this page and added to your cart.
Is there a warranty?
Concord American backs its aluminum flagpole shafts with a lifetime flagpole shaft warranty, subject to Concord American's warranty terms.
Do you install flagpoles?
Yes. Ameritex Flag & Flagpole installs flagpoles in San Antonio and the Texas Hill Country and across Texas. Use the Request Installation Quote button above or call 877-598-3524.
