Steel Flag Pole Foundation Sleeves
Product Description
Flagpole Ground Sleeves - Steel
Corrugated Steel with Steel Lightning Spike
Two-Piece Design
Our corrugated steel flag pole ground sleeves are designed for use in ground set flag pole installations. Our 2-piece design concept contains a top section made of 16-gauge galvanized corrugated steel piping, a steel base plate, and steel centering wedges welded into the base of foundation sleeve to help in leveling the flagpole. The lower section consists of a threaded 3/4" diameter steel grounding spike along with a 6" x 6" steel setting plate. This design concept allows for the concrete to completely surround the foundation sleeve.
Flag pole foundation sleeves for flagpoles up to a 75' exposed height can be shipped via UPS and Fed Ex. We can customize foundation sleeves for your particular application. Please call us to discuss design details.
4" Butt Diameter Flagpoles
"A" - 10% of Exposed Height
"B" - Sleeve Diameter = 6"
"C" - Base Plate "C" = 8"
5" Butt Diameter Flagpoles
"A" - 10% of Exposed Height
"B" - Sleeve Diameter = 8"
"C" - Base Plate "C" = 10"
6-7" Butt Diameter Flagpoles
"A" - 10% of Exposed Height
"B" - Sleeve Diameter = 10"
"C" - Base Plate "C" = 12"
8" Butt Diameter Flagpoles
"A" - 10% of Exposed Height
"B" - Sleeve Diameter = 12"
"C" - Base Plate "C" = 14"
10-12" Butt Diameter Flagpoles
"A" - 10% of Exposed Height
"B" - Sleeve Diameter = 15"
"C" - Base Plate "C" = 16"
